Our process begins when a homeowner describes symptoms such as fluctuating pressure or unexpected water taste. We record fixture locations and recent changes to the plumbing system. Technicians then travel with calibrated gauges and replacement components sized for common residential assemblies. At the property they isolate sections, measure direction of flow, and confirm that check valves seat properly under both static and flowing conditions. Results are presented in plain terms that link each measurement to the risk of backflow into the supply line.
Questions about a job? Start on the Hollywood Backflow Certifications and Repairs homepage or call (855) 690-8247.
Differential Pressure Focus
Every test records the exact separation between supply and downstream pressure so reverse flow paths stay blocked.
Cross Connection Mapping
Technicians trace each potential mixing point to its isolation valve and note the condition of the nearest backflow assembly.
Component Matching
Replacement parts are selected by model number and thread specification to maintain the original rated flow capacity.
Site State Return
After work the piping layout is restored to its prior configuration with no loose fittings or standing water left behind.
Request Intake Sequence
When a call arrives we capture the exact fixture or appliance involved and any recent alterations to piping. This data determines which test ports must be accessed and which isolation valves require operation first. We note whether the property uses a single or dual check assembly so the correct gauge adapter travels with the technician. The goal is to arrive with the minimum set of parts that can restore protection without unnecessary disassembly.
Homeowners are asked to keep the main shutoff accessible and to avoid running water after reporting a suspected failure. This step prevents dilution of any stagnant water that may have crossed a failed check valve. We confirm the presence of a thermal expansion tank because its absence can mask pressure readings during the test sequence.
On-Site Test Protocol
Technicians begin by locating the backflow preventer and verifying that upstream and downstream shutoffs operate smoothly. A differential pressure gauge is connected to the test cocks and readings are taken with the relief valve open and closed. Each measurement confirms whether the check valves maintain at least one pound per square inch separation, the threshold that blocks reverse flow under supply pressure loss.
If a cross-connection is found, such as a hose bib without a vacuum breaker feeding an irrigation line, the path is traced to the nearest point where potable water could mix. The technician records the exact valve model and serial so replacement parts match thread patterns and pressure ratings without trial fittings.
Explanation of Measurements
Findings are presented by showing the gauge face and explaining what each number represents for supply protection. A drop below the required differential indicates debris on the seat or a weakened spring, either of which can allow non-potable water to enter under back-siphonage conditions. We map the affected zone on the property so the homeowner understands which fixtures remain isolated until repairs finish.
Alternative causes such as thermal expansion or a closed downstream valve are ruled out before any component is replaced. This sequence prevents unnecessary part swaps and keeps the original assembly functional when only external conditions created the symptom.
Site Restoration Steps
After reassembly each test cock is capped and the area around the device is wiped to remove any water that escaped during draining. Debris from packing nuts or old gaskets is collected so nothing remains on floors or in landscaping beds. The main water supply is returned to service gradually while pressure is monitored at an indoor faucet to confirm stable flow.
